Fanuc M-20iB/35S
Description
With its compact design and narrow arm, the M-20iB/35S Fanuc robot can lift up to a full 35 kg. It is ideal for high payload applications that require a small footprint such as pick and place, packing, palletizing as well as loading and machine tending.
Call on RobotWorld for your next automation project at 313-242-0505 or leave a message by clicking the contact us button below! We are an authorized Fanuc Integrator and can specify the proper robot for your application.
Motion Range
| J1: | 340° |
| J2: | 240° |
| J3: | 301.5° |
| J4: | 400° |
| J5: | 260° |
| J6: | 540° |
Maximum Speed
| J1: | 205 |
| J2: | 205 |
| J3: | 260 |
| J4: | 415 |
| J5: | 415 |
| J6: | 880 |
Applications
Specifications
| Manufacturer | Fanuc |
| Model | M-20iB/35S |
| Condition | New |
| Axes | 6 |
| Payload | 35 kg |
| H-Reach | 1445 mm |
| Repeatability | ±0.02 mm |
| Robot Mass | 205 kg |
| Controller | R30iB |
| Mounting | Floor, Inverted, Angle |
